1978-1994 Chevy Van LED Digital Panel - DP1605


This sleek, classy designed 1978-1994 Chevy Van LED Digital Replacement Gauge Panel from Intellitronix will jazz up your 1978-94 Chevy Van and give it pizzazz. The 1978-1994 Chevy Van LED Digital Dash Panel comes complete with direct fit printed circuit boards, custom fit "smoked" plexiglass faceplate, universal temperature, oil pressure, and speedometer sending units with senders and sensors for vehicles without electronic transmission or cruise control, and instructions for installation.


Speedometer and Tachometer combines a microprocessor-controlled speedometer that reads up to 255 MPH with a built-in Tachometer that reads from 0 to 9900 RPM in 100 RPM increments. The combination features odometer, trip meter, one-button calibration, regardless of tire size, gear ratio or transmission, and 0-60 time, 1⁄4 mile elapsed time, and high speed recall, all with the push of a button. The speedometer can be used with electronic cruise control senders or use included S9013 universal speedometer sending unit, if your vehicle is not equipped with a functional cruise control. Applicable to any mechanical or electronic transmission. It is accurate, super bright, and intelligent all in one. The future of digital is here.


Water Temperature display with 18-250°F range with sender S8013 included. Please specify bushing size for sender as we normally send a 1/2 inch one, but we can send a 3/8 inch one instead upon request. Please just add a note at check-out; otherwise, you will have to get the correct bushing on your own.


Oil Pressure displays 0-100 PSI range. Oil pressure sender included.


Voltmeter reads 7.0-18.0 volts range and no sending unit is required.


Fuel Level displays 0-99% range in 1% increment and works with existing GM fuel level sending unit.


The panels also feature highbeam and brake indicator making it the ultimate way to keep the ride you love cruising through the times.


Easy Install, Lifetime Warranty, Great Price, & Gauges for your very special classic vehicle.







AVAILABLE COLORS:  White, Red, Blue, Green, and Teal

SPEEDOMETER READING:  Order your speedometer in either MPH or KPH


ACCESSORIES:  All required sending and sensor units are included.
